NOVARIONS FILTRONIX Agitated Nutsche Filter Dryer (ANFD) is an advanced, fully enclosed filtration and vacuum drying system designed to perform solid-liquid separation, cake formation, cake washing, de-liquoring, mixing and vacuum drying in a single vessel.
Designed for the pharmaceutical, API, specialty chemical, fine chemical, agrochemical and nutraceutical industries, the ANFD is suitable for high-value products where product containment, purity, controlled processing and consistent drying performance are critical.
The Agitated Nutsche Filter Dryer combines a robust filtration vessel with an integrated agitator system, enabling controlled cake leveling, washing, re-slurrying, de-liquoring and drying without transferring the product between separate equipment. This single-vessel operation helps reduce product handling, contamination risks and material losses.
During vacuum drying, controlled heating, vacuum and agitation help remove residual moisture and solvents while improving heat and mass transfer through the filter cake. The process can be precisely controlled according to the product and drying requirements.
NOVARIONS FILTRONIX ANFD can be customized with SS304, SS316, SS316L, Hastelloy and other suitable materials of construction, along with different filter media, agitator configurations, heating systems and discharge arrangements based on the process requirements.
The system can also be supplied with GMP-oriented design, ATEX-compatible configurations and PLC/HMI automation, including VFD-controlled agitation, temperature and pressure monitoring, vacuum control, automatic process sequencing, alarms, safety interlocks and batch data logging.
By integrating multiple process operations into one closed vessel, the NOVARIONS FILTRONIX Agitated Nutsche Filter Dryer provides an efficient solution for pharmaceutical filtration and drying, API processing, chemical filtration, solvent-based processes and demanding solid-liquid separation applications.
Sizes
Materials of
Coatings | MODEL | Filtration Area (SQ. M) | Working Volume (Liters) | Cake Holding Volume Max (Liters) | Vessel ID (mm) | Vessel Height (mm) | Agitator Stroke Max (mm) | Discharge Valve Dia (mm) | Agitator RPM | Motor Load (kw) |
|---|---|---|---|---|---|---|---|---|---|
| SS/ANFD - 10 | 0.04 | 10 | 3 | 220 | 330 | 80 | 50 | 15-120 | 1.5 |
| SS/ANFD - 25 | 0.07 | 25 | 8 | 300 | 450 | 120 | 65 | 12-120 | 2.2 |
| SS/ANFD - 50 | 0.1 | 50 | 17 | 380 | 570 | 150 | 65 | 8-10 | 3 |
| SS/ANFD - 100 | 0.2 | 100 | 32 | 500 | 550 | 175 | 150 | 5-50 | 4 |
| SS/ANFD - 200 | 0.32 | 230 | 80 | 640 | 720 | 250 | 200 | 7-74 | 4 |
| SS/ANFD - 250 | 0.38 | 280 | 115 | 700 | 750 | 300 | 200 | 7-70 | 5.5 |
| SS/ANFD - 350 | 0.5 | 400 | 150 | 800 | 800 | 300 | 200 | 6-60 | 5.5 |
| SS/ANFD - 500 | 0.7 | 640 | 210 | 955 | 900 | 300 | 200 | 5-46 | 7.5 |
| SS/ANFD - 750 | 0.85 | 770 | 340 | 1050 | 900 | 400 | 250 | 4-40 | 7.5 |
| SS/ANFD - 1000 | 1.26 | 1140 | 505 | 1270 | 900 | 400 | 250 | 4-37 | 11 |
| SS/ANFD - 1500 | 1.5 | 1500 | 750 | 1380 | 1000 | 500 | 250 | 3-30 | 15 |
| SS/ANFD - 2000 | 2 | 2000 | 1000 | 1600 | 1000 | 500 | 350 | 3-30 | 18.5 |
| SS/ANFD - 2500 | 2.5 | 2500 | 1250 | 1800 | 1000 | 500 | 350 | 3-25 | 18.5 |
| SS/ANFD - 3000 | 3 | 3000 | 1500 | 1960 | 1000 | 500 | 350 | 3-25 | 22 |
| SS/ANFD - 4000 | 4 | 4000 | 2000 | 2260 | 1000 | 500 | 350 | 2-21 | 22 |
| SS/ANFD - 5000 | 5 | 5000 | 2500 | 2535 | 1000 | 500 | 350 | 2-18 | 30 |
| SS/ANFD - 6000 | 6 | 6000 | 3000 | 2765 | 1000 | 500 | 350 | 2-17 | 30 |
| SS/ANFD - 7000 | 7 | 7000 | 3500 | 3000 | 1000 | 500 | 450 | 2-16 | 37 |
| SS/ANFD - 8000 | 8 | 8000 | 4000 | 3190 | 1000 | 500 | 450 | 2-15 | 37 |
| SS/ANFD - 9000 | 9 | 9000 | 4500 | 3390 | 1000 | 500 | 450 | 2-15 | 45 |
| SS/ANFD - 10000 | 10 | 10000 | 5000 | 3570 | 1000 | 500 | 450 | 2-14 | 45 |
| SS/ANFD - 12000 | 12 | 12000 | 6000 | 3910 | 1000 | 500 | 450 | 1-12 | 55 |
| SS/ANFD - 15000 | 15 | 15000 | 7500 | 4200 | 1000 | 500 | 450 | 1-10 | 60 |
| SS/ANFD - 20000 | 20 | 20000 | 10000 | 5000 | 1000 | 500 | 450 | 1-9 | 75 |
| Feature | Description |
|---|---|
| Equipment | Agitated Nutsche Filter Dryer (ANFD) |
| Primary Function | Integrated solid-liquid separation and vacuum drying |
| Process Integration | Filtration, washing, de-liquoring and drying in a single vessel |
| Filtration Principle | Pressure or vacuum-assisted filtration through a perforated filter plate |
| Cake Formation | Uniform filter cake formation for consistent filtration performance |
| Cake Leveling | Agitator-operated cake leveling for uniform cake thickness |
| Cake Washing | Controlled washing for effective removal of mother liquor and impurities |
| Re-Slurrying | Agitator-assisted re-slurrying for improved product purification |
| De-liquoring | Mechanical and vacuum-assisted removal of residual liquid |
| Vacuum Drying | Controlled vacuum drying for moisture and solvent removal |
| Agitation | Variable-speed agitation for filtration, washing, mixing and drying |
| Agitator Drive | Robust drive arrangement designed for reliable batch operation |
| VFD Control | Variable-frequency drive for precise agitator speed control |
| Heating | Jacketed heating for controlled and uniform product temperature |
| Cooling | Jacket cooling option for controlled product cooling after processing |
| Heat Transfer | Optimized vessel and jacket design for efficient heat transfer |
| Vacuum System | Vacuum connection and control arrangement for drying and de-liquoring |
| Pressure Operation | Designed according to specified process pressure and vacuum requirements |
| Vessel Design | Robust cylindrical vessel with optimized filtration and agitation geometry |
| Filter Plate | Customized filter plate design according to product and filtration requirements |
| Filter Media | Selection of filter cloth, mesh or suitable filtration media based on application |
| Discharge System | Customized bottom or side discharge arrangement |
| Product Recovery | Designed to minimize product hold-up and improve product recovery |
| Containment | Fully enclosed processing to reduce operator exposure and product contamination |
| Solvent Handling | Suitable for solvent-based filtration and drying applications |
| MOC Options | SS304, SS316, SS316L, Hastelloy and other materials as required |
| Surface Finish | Internal surface finish customized according to process and pharmaceutical requirements |
| Seal Arrangement | Process-compatible sealing system for reliable closed operation |
| Pharmaceutical Design | GMP-oriented design options for pharmaceutical and API applications |
| ATEX Configuration | ATEX-compatible electrical and instrumentation options for hazardous areas |
| Automation | PLC/HMI-based automatic process control available |
| Process Sequencing | Automated filtration, washing, drying and agitation sequences |
| Temperature Control | Continuous monitoring and control of product temperature |
| Pressure Monitoring | Process pressure and vacuum monitoring |
| Safety Interlocks | Integrated safety interlocks for critical operating conditions |
| Alarm Management | Configurable alarms for temperature, pressure, vacuum and equipment conditions |
| Data Logging | Batch process data logging and monitoring options |
| Recipe Management | Recipe-based process control for repeatable batch production |
| Cleaning | Design options supporting efficient equipment cleaning and maintenance |
| Inspection | Access arrangements for inspection, maintenance and filter-media replacement |
| Documentation | GA drawings, MTCs, inspection reports, testing documents and IOM manuals available |
| FAT / SAT | Factory Acceptance Test and Site Acceptance Test support available |
| Applications | API, pharmaceutical, specialty chemicals, fine chemicals, agrochemicals and nutraceuticals |
| Process Benefit | Reduced product transfer, lower contamination risk, improved containment and efficient processing |
| Manufacturing | Engineered and manufactured according to customer process requirements |
| Customization | Capacity, filtration area, pressure, vacuum, temperature, agitation and discharge can be customized |
